DCR-504 Door Closer, EN Size 4, Silver

DCR-504
Mechanical Products
₹ 1,199 MRP ₹ 1,499
20%
OFF

(inclusive of taxes)

Delivery :
  • Check
Designed to meet EN1154 500,000 cycles tested Staked valves allow precise speed adjustment and avoid valve backout High quality steel spring sealed in hydraulic fluid for superior performance Graded aluminium body with triple protection paint to avoid corrosion Noise free operation Product Specification: Size EN2 to EN4 (Template adjustable) Maximum door size 1000mm, 60kg Closing speed angle 180 ~ 15 degree Latching Speed angle 15 ~ 0 degree Maximum opening angle 180 degree Arm Type - Regular, Parallel & Hold open
  • High quality steel spring sealed in hydraulic fluid for superior performance
  • Graded aluminum body with triple protection paint to avoid corrosion
  • Size EN4
  • Maximum door size 1000mm, 60kg
  • Closing speed angle 180 ~ 15 degree, Maximum opening angle 180 degree
  • Type : Surface mounted
  • Technology : Rack & Pinion
  • Material: Aluminum
  • Color: Silver
  • Item Dimension: 177mm x 40mm x 63mm
  • Suitable for Left & Right Hand opening doors
  • Suitable for Door width : Upto 1100mm
  • Suitable for Door weight : Upto 80kg
  • Speed Adjustment : Two (Closing & Latching)

Warranty : 3 years from the date of purchase
